MOGAMI 8-core digital snake cable (3162)

110Ω AES/EBU digital audio cable

3162-0

Product lists can be submitted to HHB for a packaged quotation

Add to Product List
Add to Product List



As with the world standard MOGAMI 293x multicore microphone cable, Mogaim multicore 110Ω AES/EBU digital audio cables are flexible and compact. Making them ideal for wiring, installation and handling. A larger conductor size is used, which naturally results in lower attenuation. This is achieved with a compact overall diameter by using a cellular PP (polypropylene) insulation material. The cable’s jacket and inner conductors provide printed channel numbers, in addition to a colour coding system used for identification by standard resistor colour code. Each channel has a drain wire and served (spiral) bare copper shield.  Rugged and flexible construction that is easy to handle, even at temperatures down to -20°C. Overall diameter 9mm. Available in black only.
